ZenaDrone IQ Sphere

Autonomous Inspection, Surveillance & Reconnaissance (ISR) Drone (Initial Prototype)

Multipurpose Defense Omnicopter

The ZenaDrone IQ Sphere is built for autonomous ISR in confined and GPS- or RF-denied environments. Designed for defense and dual-use commercial applications, the IQ Sphere’s 360° imaging capability supports high-risk missions including building clearance and ship boarding, inspection of underground tunnels and mines, collapsed structures, pipeline interiors, ship hulls, and cave systems, as well as critical infrastructure security and hazardous industrial operations.

Key Features

Spherical Omnicopter

Features six degrees of freedom (6DOF) for operation in confined and complex environments.

360° Imaging

Tilt-free platform provides instant and comprehensive situational awareness.

GPS- & RF-Denied Operation

Designed to operate in environments where GPS and radio-frequency signals may be unavailable or restricted.

Modular Architecture

An adaptable platform supports cameras, sensors, and manipulators for different mission requirements.

Built for Complex Environments

The IQ Sphere’s lightweight, protective frame enables operation in confined infrastructure and underground spaces as well as challenging maritime and industrial environments, giving operators advanced visibility where conventional ISR methods can be difficult, hazardous, or impractical.

Vehicle Specifications

Dimensions

Sphere Diameter

56 cm (22 in)

Weight

Empty Weight

5.5 kg (12 lbs)

Max Takeoff Weight

5.5–6 kg (12–13 lbs)

Payload

400 g (0.88 lbs)

Flight

Hovering Endurance

12–15 minutes

Attachment Mechanism

Material

Carbon Fiber

Load Capacity

400 g (0.88 lbs)

Compatible Attachments

Cameras, Sensors, Manipulators

Wireless Charging

Input

120–260 V AC
